Electrical
Frequency Range: 20 - 300 MHz
VSWR:
Average: 1.4:1 with 6 dB pad
Maximum: 1:8:1 with 6 dB pad
Max. Cont. Power: 0.5 W
Peak Power: 1.0 W
Input Impedance: 50 Ohms
Output Connector: BNC, female
Mechanical
- Length: 129.8 cm (51") tip-to-tip
- Diameter: 50.8 cm (20")
- Depth: 54 cm (21.5") including balun
Weight: 2.7 kg (6 lbs.)
