Source/Measure Unit (SMU) di precisione, 1 canale, 210 V, 3 Adc, 10.5 A pulse, risoluzione 10 fA.
Channel: 1
Source (DC)
Voltage: ±210 V
Current: ±3.03 A
Pulsed: ±10.5 A
Maximum resolution
Source: 2.100.000
Measurement: 2.100.000
Current resolution
Source: 10 fA
Measurement: 10 fA
Voltage resolution
Source: 100 nV
Measurement: 100 nV
Current range(DC): 10 nA - 3 A
Voltage range: 200 mV - 200 V
Minimum trigger interval: 10 μs
